C95400 Aluminum bronze :
C95400(CuAl10Fe) Aluminum bronze is the most common cast aluminum bronze, C95400 is used in many heavy duty, high load and high wear applications. Good tensile strength, ductility, weldability and resistance to fatigue. Typical applications include worm gears, bushings, pump parts and bearings.
Chemical Composition
| Cu | Sn | Pb | Zn | Fe | Ni | Sb | Al | Mn | Si |
| 83.00-87.00 | N/A | N/A | N/A | 3.00-5.00 | 1.5 | N/A | 10.0-11.50 | 0.5 | N/A |
Mechanical Properties
|
Tensile Strength (min) |
Yield Strength (at .5% extention under load min) |
Elongation (in 2in. or 50mm min, %) |
Brinell Hardness (min) |
Remarks |
||
|
Ksi |
MPa |
Ksi |
MPa |
|
|
|
|
85 |
485 |
32 |
195 |
12 |
150 |
|
Capway, one of the professional alloy bronze c95400 cual11fe4 aluminium bronze ab1-c manufacturers, is also known as an excellent supplier in China. We now bring you the best quality alloy bronze c95400 cual11fe4 aluminium bronze ab1-c with high precision and reliable performance. Should you are interested in it, please feel free to get in touch with our factory.
